Brand New Original Bosch Rexroth Servo drive MS2N03-B0BYN-HMSH1-NNNNE-NN Servo Motor Fast Shipping

MS2N03-B0BYN-HMSH1-NNNNE-NN, Bosch Rexroth Indramat, MS2N Synchronous Servo Motors delivers precise motion control through an AC synchronous design, requiring 200 to 480 Volts AC at 50 to 60 Hz input. This model features a high-speed capability up to 6470 rpm and a robust standstill torque of 0.73 Nm. The compact construction integrates a Multiturn absolute encoder with 4096 increments resolution and an ACURO link protocol for real-time position and temperature feedback. An included PT1000 temperature sensor enhances thermal monitoring for reliable performance under varying loads.

Engineered for versatility and endurance, the MS2N03-B0BYN-HMSH1-NNNNE-NN draws only 1.31 Amperes at standstill, achieving a torque constant of 0.6 Nm per ampere for efficient current-to-torque conversion. The motor’s 58 mm flange size and smooth, seal-free shaft facilitate straightforward integration into compact assemblies. A corrosion-resistant coating on the enclosure allows safe operation up to 1000 meters altitude, while the approved operating temperature range of 0 to 40 degrees Celsius and storage range of -20 to 80 degrees Celsius protect the motor in harsh environments.

Installation and maintenance are simplified by the motor’s single-cable M23 connection and turnable connector body, reducing cabinet complexity and wiring time. The integrated Multiturn encoder and PT1000 sensor data stream via the ACURO link ensures seamless communication with Bosch Rexroth drive modules, supporting closed-loop control and predictive maintenance strategies. This reliable, high-precision servo motor is ideal for robotics, packaging machinery, and automated assembly lines where exact positioning and robust environmental tolerance are paramount.
